基于单片机的温湿度实时测量系统的设计(论文9300字)
摘要:温湿度的测量在生物用品、医药卫生、食品安全、科学研究、国防建设等方面直接或者间接地影响着人类的生活。所以对于温湿度数据的精准测量是本设计的关键部分。
该硬件的设计包括:主控制模块,液晶显示器,报警模块,输入模块的键和其他组件。在环境中,DHT11湿度传感器是作为STC89C51的中心装置而建立的,按键输入预先设定的值,如果收集到的话。a.数据不符合规定值,蜂鸣器发出警报并启动相应的控制。可用性,显示子程序,软件布局。以此来达到对环境中的温湿度的实时监测。
关键词: DHT11温湿度传感器; STC89C51单片机。

Temperatureandhumidityreal-timemeasurementsystembasedonsingle-chipmicrocomputer
Absrtact: The measurement of temperature and humidity directly or indirectly affects human life in the fields of biological products, medicine and health, food safety, scientific research and national defense construction. Therefore, accurate measurement of temperature and humidity data is the key part of this design.
The hardware design includes: main control module, liquid crystal display, alarm module, key of input module and other components. In the environment, DHT11 humidity sensor is built as the central device of STC89C51. Preset values are input by keys, if collected. A. Data do not meet the required value, buzzer alarm and start the corresponding control. Usability, display subroutines, software layout. In order to achieve real-time monitoring of temperature and humidity in the environment.
Key words: DHT11 temperature and humidity sensor; STC89C51 single chip computer.


基于单片机的温湿度实时测量系统的设计
基于单片机的温湿度实时测量系统的设计


目 录
1.绪论    1
1.1研究背景与意义    1
1.2国外研究现状    1
1.3国内研究现状    1
2.温湿度控制系统总体设计    2
2.1设计要求    2
2.2传感器的选择    2
2.3单片机的选择    2
2.4总体设计    2
3.硬件设计    4
3.1主控模块    4
3.1.1 STC89C51简介    5
3.1.2最小系统电路    6
3.2液晶显示模块    7
3.2.1 1602液晶简介    7
3.2.2液晶引脚说明    8
3.2.3液晶显示模块电路    8
3.3报警模块    9
3.3.1声音报警子模块    9
3.3.2 LED报警子模块    9
3.4按键输入模块    10
4.软件设计    11
4.1程序语言及开发环境    11
4.2系统流程图    12
5.系统调试    13
5.1元件的焊接与组装    13
5.2电路调试    15
5.3实验结果与数据分析    17
6.总结    21
参考文献    22
致谢    23
